Caja fuerte IOT con teclado o sistema de cierre RFID

En este artículo nos gustaría mostrar cómo construir una caja fuerte IOT con teclado o bloqueo RFID. El siguiente vídeo es la instrucción. Proporcionamos información adicional a través de la entrada del blog.

 Aquí encontrará los productos utilizados:

• ESP32 D1 Mini (https://www.az-delivery.de/products/e...)
• Módulo reductor CC-CC LM2596S (https://www.az-delivery.de/products/l...)
• 5V Anillo LED WS2812B (https://www.az-delivery.de/products/r...)
• Servomotor MG995 (https://www.az-delivery.de/products/a...)
• Teclado Matrix 4x4 (https://www.az-delivery.de/products/4...)
• Kit RFID RC522 (incluye lector, chip y tarjeta) (https://www.az-delivery.de/products/r...)

 Cableado del teclado:

Teclado de códigos:

/*
    ___ _____        ____       ___
   /   /__  /       / __ \___  / (_)   _____  _______  __
  / /| | / / ______/ / / / _ \/ / / | / / _ \/ ___/ / / /
 / ___ |/ /_/_____/ /_/ /  __/ / /| |/ /  __/ /  / /_/ /
/_/  |_/____/    /_____/\___/_/_/ |___/\___/_/   \__, /
                                                /____/
 Producto, hoja de datos y pinout en:
  https://www.az-delivery.de/

 Proyecto: Caja fuerte con teclado e iluminación interior
 Fecha: 10/2022

 Control de teclado del sketch de ejemplo de la librería de Chris--A:
  https://github.com/Chris--A/Keypad/blob/master/examples/CustomKeypad/CustomKeypad.ino

*/
#include <Arduino.h>
#include <ESP32Servo.h>
#include <SPI.h>
// #include <MFRC522.h>
#include <fastLED.h>
#include <Keypad.h>

// motor
const int servoPin = 2;
Servo myservo;

// leds
const int NUM_LEDS = 12;
const int DATA_PIN = 25;
CRGB leds[NUM_LEDS];
int randomRed = 0;
int randomGreen = 0;
int randomBlue = 0;
const int LEDRed = 4;

bool dooropen = false;

// Keypad
const byte ROWS = 4;    // four rows
const byte COLUMNS = 4; // four columns
// define the symbols on the buttons of the keypads
char hexaKeys[ROWS][COLUMNS] = {
    {'1', '2', '3', 'A'},
    {'4', '5', '6', 'B'},
    {'7', '8', '9', 'C'},
    {'*', '0', '#', 'D'}};
byte rowPins[ROWS] = {16, 17, 21, 22};   // connect to the row pinouts of the keypad
byte colPins[COLUMNS] = {26, 18, 19, 23}; // connect to the column pinouts of the keypad


Keypad keypad = Keypad(makeKeymap(hexaKeys), rowPins, colPins, ROWS, COLUMNS);

const String password = "1234"; // change your password here
String input_password;

void setup()
{
  Serial.begin(115200);
  pinMode(LEDRed, OUTPUT);
  myservo.attach(servoPin);
  FastLED.addLeds<WS2812, DATA_PIN, GRB>(leds, NUM_LEDS);
  input_password.reserve(32); // maximum input characters is 33, change if needed
}

void loop()
{
  char key = keypad.getKey();

  if (key)
  {
    Serial.println(key);

    if (key == '#')
    {
      if (password == input_password)
      {
        Serial.println(" Password is correct");
        if (dooropen)
        {
          myservo.write(90); // move MG996R's shaft to angle 0°
          for (int i = 0; i < NUM_LEDS; i++)
          {
            leds[i].setRGB(0, 0, 0); // leds off
          }
          FastLED.setBrightness(20);
          FastLED.show();
          dooropen = false;
          delay(1000);
        }

        else if (dooropen == false)
        {
          myservo.write(0); // move MG996R's shaft to angle 90°
          randomRed = random(1, 256);
          randomBlue = random(1, 256);
          randomGreen = random(1, 256);

          for (int i = 0; i < NUM_LEDS; i++)
          {
            leds[i].setRGB(randomRed, randomGreen, randomBlue); // leds on with random colours
          }
          FastLED.setBrightness(20);
          FastLED.show();
          dooropen = true;
          delay(1000);
        }
      }
      else
      {
        digitalWrite(LEDRed, HIGH);
        delay(1000);
        digitalWrite(LEDRed, LOW);
      }
      input_password = ""; // clear input password
    }

    else if (key == '*')
    {
      input_password = ""; // clear input password
    }
    else
    {
      input_password += key; // append new character to input password string
    }
  }
}

Cableado RFID:

Código RFID:

/*
    ___ _____        ____       ___
   /   /__  /       / __ \___  / (_)   _____  _______  __
  / /| | / / ______/ / / / _ \/ / / | / / _ \/ ___/ / / /
 / ___ |/ /_/_____/ /_/ /  __/ / /| |/ /  __/ /  / /_/ /
/_/  |_/____/    /_____/\___/_/_/ |___/\___/_/   \__, /
                                                /____/
 Producto, hoja de datos y pinout en:
  https://www.az-delivery.de/

 Proyecto: Caja fuerte con RFID y conexión Node-RED mediante MQTT
 Fecha: 10/2022

*/
#include <Arduino.h>
#include <ESP32Servo.h>
#include <SPI.h>
#include <MFRC522.h>
#include <fastLED.h>

// for MQTT
#include <PubSubClient.h>
#include <WiFi.h>
//für etwaigen späteren Gebrauch für MQTT etc.
#include <ArduinoJson.h>
#include <AsyncTCP.h>
#include "credentials.h"

// MQTT
String clientId = "ESP32-";
const char *mqtt_server = "192.168.178.42";
const char *mqtt_user = "azdelivery";
const char *mqtt_password = "myhiddenpassword";
WiFiClient espClient;
PubSubClient client(espClient);
long lastMsg = 0;
char msg[50];
int value = 0;

// RFID
const int SS_PIN = 5;
const int RST_PIN = 27;
MFRC522 rfid(SS_PIN, RST_PIN);

// motor
const int servoPin = 2;
Servo myservo;

// leds
const int NUM_LEDS = 12;
const int DATA_PIN = 25;
CRGB leds[NUM_LEDS];
int randomRed = 0;
int randomGreen = 0;
int randomBlue = 0;
const int LEDRed = 4;

bool dooropen = false;

void reconnect()
{
  // Loop until we're reconnected
  while (!client.connected())
  {
    Serial.print("Attempting MQTT connection...");
    // Attempt to connect
    clientId += String(random(0xffff), HEX);
    if (client.connect(clientId.c_str(), mqtt_user, mqtt_password))
    {
      Serial.println("connected");
      // for this example not necessary
      // client.subscribe("topic");
    }
    else
    {
      Serial.print("failed, rc=");
      Serial.print(client.state());
      Serial.println(" try again in 5 seconds");
      // Wait 5 seconds before retrying
      delay(5000);
    }
  }
}

// only required if we get informations from mqtt

void callback(char *topic, byte *message, unsigned int length)
{
  Serial.print("Message arrived on topic: ");
  Serial.print(topic);
  Serial.print(". Message: ");
  String messageTemp;

  for (int i = 0; i < length; i++)
  {
    Serial.print((char)message[i]);
    messageTemp += (char)message[i];
  }
  Serial.println();

  if (String(topic) == "topic")
  {
    // action
  }
}

void connectAP()
{

  Serial.println("Connecting to WiFi..");
  WiFi.begin(ssid, password);

  int cnt = 0;
  while (WiFi.status() != WL_CONNECTED)
  {
    delay(1000);
    Serial.print(".");
    cnt++;

    if (cnt > 30)
      ESP.restart();
  }
  Serial.println(WiFi.localIP());
}

void setup()
{
  Serial.begin(115200);
  pinMode(LEDRed, OUTPUT);
  SPI.begin();     // start SPI bus
  rfid.PCD_Init(); // start RFID-Modul
  Serial.println("RFID-RC522 ist bereit");

  myservo.attach(servoPin);

  FastLED.addLeds<WS2812, DATA_PIN, GRB>(leds, NUM_LEDS);

  connectAP();
  client.setServer(mqtt_server, 1883);
  client.setCallback(callback);
}

void loop()
{

  if (!client.connected())
  {
    reconnect();
  }
  if (!client.loop())
    client.connect("ESP32Tresor");

  if (!rfid.PICC_IsNewCardPresent())
  {
    return;
  }
  if (!rfid.PICC_ReadCardSerial())
  {
    return;
  }

  Serial.println();
  // read the RFID-tags
  Serial.print(" UID tag  :");
  String content = "";
  for (byte i = 0; i < rfid.uid.size; i++)
  {
    Serial.print(rfid.uid.uidByte[i] < 0x10 ? " 0" : " ");
    Serial.print(rfid.uid.uidByte[i], HEX);
    content.concat(String(rfid.uid.uidByte[i] < 0x10 ? " 0" : " "));
    content.concat(String(rfid.uid.uidByte[i], HEX));
  }
  content.toUpperCase();
  Serial.println();
  Serial.print(" PICC type: ");
  MFRC522::PICC_Type piccType = rfid.PICC_GetType(rfid.uid.sak);
  // the returned hex-value can be used for further actions

  Serial.println(rfid.PICC_GetTypeName(piccType));

  if (content.substring(1) == "AC 32 E6 8C")
  {

    if (dooropen)
    {
      myservo.write(90); // move MG996R's shaft to angle 0°
      for (int i = 0; i < NUM_LEDS; i++)
      {
        leds[i].setRGB(0, 0, 0); // leds off
      }
      FastLED.setBrightness(50);
      FastLED.show();
      dooropen = false;
      delay(1000);
    }

    else if (dooropen == false)
    {
      myservo.write(0); // move MG996R's shaft to angle 90°
      randomRed = random(1, 256);
      randomBlue = random(1, 256);
      randomGreen = random(1, 256);

      for (int i = 0; i < NUM_LEDS; i++)
      {
        leds[i].setRGB(randomRed, randomGreen, randomBlue); // leds on with random colours
      }
      FastLED.setBrightness(50);
      FastLED.show();
      client.publish("safe", "Your safe has been opened"); // E-Mail
      dooropen = true;
      delay(1000);
    }
  }
  else
  {
    digitalWrite(LEDRed, HIGH);
    delay(1000);
    digitalWrite(LEDRed, LOW);
    delay(1000);
  }
}

Credenciales para esto:

const char* ssid = "myhiddenSSID";
const char* password = "mytopsecreitpassword";
