Highly scalable from a single 64-LED panel to a small LED wall, the bright red modules are suitable for displays with long-distance effects. The AZDelivery LED matrix with 256 LEDs consumes a maximum of only 160 mA, so that it can be conveniently operated without an additional energy source, e.g. via a microcontroller. The MAX7219 LED drivers are controlled via SPI data protocol using only 5 cables - even if you connect several modules together.

Different effects can be achieved with different controllers: Spectrum music mode, rolling subtitle, image display, video display, fireworks effect and chase effect.

Particularities

Since the LEDs of the display are individually addressable, you can set the LEDs to scroll messages or show images on the display.
Compared to other matrix displays, this display module is very cost-efficient and allows you to reduce the usage cost.
The linkable and compatible design of the display allows expansion of the matrix panel.

Technical specifications

Dimensions	128 x 32 x 15mm
Material	PCB
Chip	Max7219
LED color	Red
Power supply	From 3.3V to 5V DC
Working current DC	30mA - 80mA
Operating voltage	From +3.3V to +5V DC
Operating temperature	from -10 ° C to 80 ° C
Changeable brightness	in software
Brightness	digital and analog

Cost -effective design

Made from high -quality materials, the Matrix display has a cost -effective and compact design and thus enables reduction in the costs.

Quick start guide

When buying one of our high-quality products, you will also receive an inclusive e-book for a quick introduction to the world of microelectronics.
